Noble, functional and elegant - the Jaeger 10 Timber LX

Bolt action rifle Jaeger JAEGER 10

The bolt action rifle with cylinder breech is the hunting rifle par excellence for raised hide, driven hunt and stalk. In this class, the JAEGER 10 relies on uncompromising functionality and the high security of the cylinder lock – a classic that has proven itself a million times over, reissued. The Haenel developers have created a rifle that can be a daily companion for hunters in the field: robust, easy to handle and yet with a no-frills aesthetic in many variants with wooden or plastic stocks.

Jaeger 10 Standard
Jaeger 10 Timber LX
Jaeger 10 Timber Lady
Jaeger 10 Timber Compact
Jaeger 10 Timber Lady Compact
Jaeger 10 Synthetic
Jaeger 10 Varmint
Jaeger 10 Varmint Sporter
Jaeger 10 Compact SD
Funktionell und praktisch: Die Jaeger 10

JAEGER 10 features

The legendary cold-forged Suhl barrels in many calibres – with variable sight i-Sight system and barrel thread with muzzle cap. With sights, without sights or with silencer/muzzle brake.

Bullet chamber stem with the legendary JAEGER 10 lock action. Opening angle only 60 degrees for short distances.

The two-position safety acts on the trigger bar. The rifle can be opened even when it is secured.

3+1 shot magazine can be inserted without fumbling. Also available as 10+1 in .308 Win. .

Direct trigger with back trigger (except Varmint/Compact versions).

Whether straight stock, synthetic stock or Lady-DS stock: the JAEGER 10 convinces with ergonomic stock designs.

Classic bolt-action rifle

The JAEGER 10 is manufactured with state-of-the-art technology. The high-strength cylinder lock runs perfectly in the system sleeve with the best surface and sliding properties. This breech corresponds in precision with the cold-forged Suhl barrels. The bolt action’s opening angle of only 60 degrees makes quick reloading possible. In addition, there is a dry standing trigger with a set trigger – and a removable magazine for quick magazine changes. JAEGER 10 offers everything that a light and manageable all-rounder needs.

Variants of the JAEGER 10

The choice is yours: the stock adapts the rifle to the shooter. What counts here are ergonomics and experience in the art of shaping. The JAEGER 10 is offered in a wide range of shaft variants in wood and plastic – including solutions for women and smaller men. The DS stocks grip well even with small hands and have a shorter buttstock.

“Everything a rifle needs: The JAEGER 10 is uncompromisingly simple and functional. And it can take a lot because the design is robust and proven.”

Alexander Ahrenholdt – Forester, hunter, nature photographer

The JAEGER 10 in action

A quality product that can take anything and withstand a lot – in the video the JAEGER 10…

JAEGER 10 versions

Common areas of use:

Hunting

Sports

Defence / Authorities

JAEGER 10 Standard

H

JAEGER 10 with basic wood stock for tough everyday hunting. The grade 1 stock is robust and, as traditionalists prefer, in Monte-Carlo style. Even the basic version is top-notch: cold-forged Suhl barrel and i-Sight system variable sights as standard.

Funktionell und praktisch: Die Jaeger 10
Funktionell und praktisch: Die Jaeger 10
Technical Details
Calibre (Twist) .223 Rem. (12,0") / .243 Win. (10,0") / .270 Win. (10,0") / .30-06 Spring. (11,0") / .308 Win. (12,0") / 6,5x55 SE (8,7") / 8x57IS (9,4") / 9,3x62 (14,2") / 7 mm Rem.Mag. (9,5") / .300 Win.Mag. (11,0")
Overall length 1100 mm / Magnum: 1150 mm
Barrel length 560 mm / Magnum: 610 mm
Barrel diameter Standard ∅ 17 mm
Weight approx. 3,2 kg (referred to standard-barrel)
Trigger Direct trigger with setter
Sight i-Sight system: detachable sights, with muzzle thread (M15x1) and muzzle-cap
Magazine capacity 3+1, 4+1 (.223 Rem.), optional 10+1 (.308 Win.) / Magnum: 2+1
Stock Holzschaft Klasse 1

JAEGER 10 Timber LX

H

LX stands for luxury: Noble, functional and elegant - the JAEGER 10 Timber LX shines in the details. On the one hand there is a noble walnut stock in wood class 4. On the other hand a system casing and a barrel with corrosion-resistant Illaflon coating. The Timber LX addresses hunters who cultivate a classic hunting ideology, where steel and wood enter into a symbiotic union. Selected stock wood of the "fine walnut" class makes the JAEGER 10 a showpiece.

Noble, functional and elegant - the Jaeger 10 Timber LX
Edel, funktional und elegant – die Jaeger 10 Timber LX
Technical Details
Calibre (Twist) .223 Rem. (12,0") / .243 Win. (10,0") / .270 Win. (10,0") / .30-06 Spring. (11,0") / .308 Win. (12,0") / 6,5x55 SE (8,7") / 7x64 (8,7") / 8x57IS (9,4") / 9,3x62 (14,2") / 7 mm Rem.Mag. (9,5") / .300 Win.Mag. (11,0")
Overall length 1100 mm / Magnum: 1150 mm
Barrel length 560 mm / Magnum: 610 mm
Barrel diameter Standard ∅ 17 mm
Weight approx. 3,2 kg (referred to standard-barrel)
Trigger Direct trigger with setter
Sight i-Sight system: detachable sights, with muzzle thread (M15x1) and muzzle-cap
Magazine capacity 3+1, 4+1 (.223Rem.), possible at extra charge 10+1 (.308 Win.) / Magnum: 2+1
Stock Woodstock class 4

JAEGER 10 Timber Lady

H

JAEGER 10 with lady stock as a favourable alternative to the custom stock for women and smaller men. The buttstock is made of fine wood (in class 4) and runs straight with a Monte Carlo cheek piece. This allows for upright standing - optimised for the female physiognomy. The pistol grip is steeper, therefore the trigger is easier to reach with smaller fingers. At the same time the new straight stock reduces the recoil, further supported by a specially dampening butt plate. The system casing and the barrel are provided with a corrosion-protective Illaflon coating.

Funktionell und praktisch: Die Jaeger 10 DS
Funktionell und praktisch: Die Jaeger 10 DS
Technical Details
Calibre (Twist) .223 Rem. (12,0") / .243 Win. (10,0") / .270 Win. (10,0") / .30-06 Spring. (11,0") / .308 Win. (12,0") / 6,5x55 SE (8,7") / 7x64 (8,7") / 8x57IS (9,4") / 9,3x62 (14,2") / 7 mm Rem.Mag. (9,5") / .300 Win.Mag. (11,0")
Overall length 1090 mm / Magnum: 1140 mm
Barrel length 560 mm / Magnum: 610 mm
Barrel diameter Standard ∅ 17 mm
Weight approx. 3,2 kg (referred to standard-barrel)
Trigger Direct trigger with setter
Sight i-Sight system: detachable sights, with muzzle thread (M15x1) and muzzle-cap
Magazine capacity 3+1, 4+1 (.223 Rem.), possible at extra charge 10+1 (.308 Win.) / Magnum: 2+1
Stock Woodstock class 4

JAEGER 10 Timber Compact

H

Our woodstock JAEGER 10 with a short barrel for the suppressor (and always when handiness is the trump card).

Die kurze Jaeger 10 Timber Compact mit Haenel JGR Suppressor
Technical Details
Calibre (Twist) .223 Rem. (12,0") / .243 Win. (10,0") / .30-06 Spring. (11,0") / .308 Win. (12,0") / 6,5x55 SE (8,7") / 8x57IS (9,4") / 9,3x62 (14,2")
Overall length 1050 mm (without suppressor) / approx. 1197 mm (with Haenel JGR suppressor)
Barrel length 510 mm, barrel Illaflon-coated
Barrel diameter Semi-Weight ∅ 19 mm
Weight approx. 3,3 kg
Trigger Direct trigger
Sight i-Sight system: detachable sights, with muzzle thread (M15x1) and muzzle-cap
Magazine capacity 3+1, 4+1 (.223Rem.), possible at extra charge 10+1 (.308 Win.)
Stock Woodstock class 4
Additional features Picatinny rail

JAEGER 10 Timber Lady Compact

H

JAEGER 10 in wood-finished lady's version with short barrel with silencer option: it is easy to do without bang and recoil, thanks to the short barrel the rifle remains manageable.

Eine kurze, führige Jagdbüchse: Die Jaeger 10 Compact SD
Technical Details
Calibre (Twist) .223 Rem. (12,0") / .243 Win. (10,0") / .30-06 Spring. (11,0") / .308 Win. (12,0") / 6,5x55 SE (8,7") / 8x57IS (9,4") / 9,3x62 (14,2")
Overall length 1040 mm (without suppressor) / approx. 1187 mm (with Haenel JGR suppressor)
Barrel length 510 mm / barrel Illaflon-coated
Barrel diameter Semiweight ∅ 19 mm
Weight approx. 3,3 kg
Trigger Direct trigger
Sight i-Sight system: detachable sights, with muzzle thread (M15x1) and muzzle-cap
Magazine capacity 3+1, 4+1 (.223 Rem.) / optional 10+1 (.308 Win.)
Stock Woodstock class 4
Additional features Picatinny rail

JAEGER 10 Synthetic

H

JAEGER 10 with synthetic stock. The fibreglass strengthened material is available in a dark anthracite colour, is easy to grasp even in bad weather conditions, scratch-resistant and insensitive against dirt. The stock has a symmetrical pistol grip - so it is equally suitable for right- and left-handed shooters. The i-Sight system makes the muzzle flexible (suppressor or open sights).

Unverwüstlich bei Wind und Wetter: Jaeger 10 Synthetic
Unverwüstlich bei Wind und Wetter: Jaeger 10 Synthetic
Technical Details
Calibre (Twist) .223 Rem. (12,0") / .243 Win. (10,0") / .270 Win. (10,0") / .30-06 Spring. (11,0") / .308 Win. (12,0") / 6,5x55 SE (8,7") / 8x57IS (9,4") / 9,3x62 (14,2") / 7 mm Rem.Mag. (9,5") / .300 Win.Mag. (11,0")
Overall length 1100 mm / Magnum: 1150 mm
Barrel length 560 mm / Magnum: 610 mm
Barrel diameter Standard ∅ 17 mm
Weight approx. 3,0 kg (referred to standard-barrel)
Trigger Direct trigger with setter
Sight i-Sight system: detachable sights, with muzzle thread (M15x1) and muzzle-cap
Magazine capacity 3+1, 4+1 (.223 Rem.), possible at extra charge 10+1 (.308 Win.) / Magnum: 2+1
Stock Synthetic

JAEGER 10 Varmint

H S

The Jaeger 10 Varmint is a hunting rifle designed for precision with a semi-weight barrel, a robust synthetic stock, a bipod adapter on the fore-end and a picatinny rail. Threaded barrel M15x1. In the VARMINT SPORTER version additionally available with adjustable cheek piece - for precise shooting in different positions.

Haenel Jaeger 10 Varmint - eine auf Präzision ausgelegte Jagdbüchse
Haenel Jaeger 10 Varmint - eine auf Präzision ausgelegte Jagdbüchse
Technical Details
Calibre (Twist) .223 Rem. (12,0") / .243 Win. (10,0") / .270 Win. (10,0") / .30-06 Spring. (11,0") / .308 Win. (12,0") / 6,5x55 SE (8,7") / 6,5 Creedmoor (8,0") / .300 Win.Mag. (11,0")
Overall length 1100 mm / Magnum: 1150 mm
Barrel length 560 mm / Magnum: 610 mm
Barrel diameter Semi-Weight ∅ 19 mm
Weight approx. 3,4 kg (referred to standard-barrel)
Trigger Direct trigger
Sight without
Magazine capacity 3+1, 4+1 (.223 Rem.), possible at extra charge 10+1 (.308 Win.) / Magnum: 2+1
Stock Synthetic
Additional features muzzle thread (M15x1) with muzzle-cap / Picatinny rail / bipod adapter

JAEGER 10 Varmint Sporter

H S

The Jaeger 10 Varmint Sporter is a flexible hunting rifle designed for precision with a semi-weight barrel, robust synthetic stock, Picatinny rail and adapter for a bipod. The Sporter version also has a variable shaft back - thanks to height adjustment, you can quickly reach your goal.

Haenel Jaeger 10 Varmint Sportler - eine auf Präzision ausgelegte Jagdbüchse
Haenel Jaeger 10 Varmint Sportler - eine auf Präzision ausgelegte Jagdbüchse
Technical Details
Calibre (Twist) .223 Rem. (12,0") / .243 Win. (10,0") / .270 Win. (10,0") / .30-06 Spring. (11,0") / .308 Win. (12,0") / 6,5x55 SE (8,7") / 6,5 Creedmoor (8,0") / 10,3x60R (17,7") / .300 Win.Mag. (11,0")
Overall length 1100 mm / Magnum: 1150 mm
Barrel length 560 mm / Magnum: 610 mm
Barrel diameter Semi-Weight ∅ 19 mm
Weight approx. 3,6 kg (referred to standard-barrel)
Trigger Direct trigger
Sight without
Magazine capacity 3+1, 4+1 (.223 Rem.), possible at extra charge 10+1 (.308 Win.) / Magnum: 2+1
Stock Synthetic
Additional features muzzle thread (M15x1) with muzzle-cap / picatinny rail / bipod adapter / adjustable cheek piece

JAEGER 10 Compact SD

H

The Jaeger 10 Compact SD consists of the short silencer barrel with i-Sight system and is matched to the Haenel JGR suppressor. With the in-house overbarrel silencer from B&T (Switzerland), the Compact SD remains as easy to handle as a conventional Jaeger 10. The Supressor barrel is specially coated and only 510 mm long - with the JGR silencer screwed on, the bolt action has an overall length of just 1197 mm. The short and low-vibration 19-millimetre Supressor barrel is designed for minimal point-of-impact shifts when shooting alternately with and without a silencer.

Eine kurze, führige Jagdbüchse: Die Jaeger 10 Compact SD
Technical Details
Calibre (Twist) .223 Rem. (12,0") / .243 Win. (10,0") / .30-06 Spring. (11,0") / .308 Win. (12,0") / 6,5x55 SE (8,7") / 8x57IS (9,4") / 9,3x62 (14,2")
Overall length 1050 mm (without suppressor) / approx. 1197 mm (with Haenel JGR suppressor)
Barrel length 510 mm, barrel Illaflon-coated
Barrel diameter Semi-Weight ∅ 19 mm
Weight approx. 3,0 kg
Trigger Direct trigger
Sight i-Sight system: detachable sights, with muzzle thread (M15x1) and muzzle-cap
Magazine capacity 3+1, 4+1 (.223 Rem.), optional 10+1 (.308 Win.)
Stock Synthetic
Additional features Picatinny rail
